FEATURES AND SPECIFICATIONS: DIGITAL TEMPRATURE AND THERMOSTATE CONTROLLER FOR SOLDER BATH. S.S 304 MATERIAL IS USED FOR SOLDER BATH CARATGE TYPE HEATER FOR BETTER PERFORMANCE, ENERGY SAVER AND EASY TO CHANGE. SIZE ( IN INCH) 6” X 4” 6” X 6” 8” X 6” 8”X 8” 10”X 8” SOLDER CAPACITY 5 KG 7 KG 10 KG 14 KG 18 KG POWER SUPPLY 220V AC 50Hz 220V AC 50Hz 220V AC 50Hz 220V AC 50Hz 220V AC 50Hz HEATER SUPPLY 0.8 KW 0.8 KW 1 KW 1.2KW 1.5 KW HEATING TIME 15 MIN 20 MIN 20 MIN 20 MIN 25 MIN BATH DEPTH 50 MM 50 MM 50 MM 50 MM 50 MM TEMP. RANGE 0-400 DEGREE 0-400 DEGREE 0-400 DEGREE 0-400 DEGREE 0-400 DEGREE SIZE 10” X 10” 12” X 10” 12” X 12” 14”X12” 14”X14” SOLDER CAPACITY 22 KG 26 KG 30 KG 35 KG 42 KG POWER SUPPLY 220V AC 50Hz 220V AC 50Hz 220V AC 50Hz 220V AC 50Hz 220V AC 50Hz HEATER SUPPLY 1.8 KW 2 KW 2.5 KW 2.8KW 3 KW HEATING TIME 25 MIN 25 MIN 30 MIN 30 MIN 35 MIN BATH DEPTH 50 MM 50 MM 50 MM 50 MM 50 MM TEMP. RANGE 0-400 DEGREE 0-400 DEGREE 0-400 DEGREE 0-400 DEGREE 0-400 DEGREE 1 YEAR WARRANTY OPTIONAL ACCESSORIES – TUSER FOR HOLDING PCB DURING SOLDERING. CUSTOM SIZES ARE ALSO AVAILABLE ON ORDER.
